產品描述Product description
◆FA1-6B系列是一款通用型的扳機開關，集成防塵功能，廣泛應用于各類手持式電動工具，如：電鉆、電錘、往復鋸、曲線鋸、攪拌器、型材切割機、石材切割機、電圓鋸、電木銑、砂帶機、砂光機、電刨、電動噴槍、電動釘槍，也可應用于電動園林工具，如：打草機、電鏈鋸、電動割草機、電動掃雪機等。
◆FA1-6B series are general type trigger switch, integrated dustproof, commonly for used in portable power tools such as Electric Drills, Rotary Hammers, Reciprocating Saws, Jig Saws, Electric Mixers, Cut-Off Machines, Marble Cutters, Electric Routers, Circular Saws, Belt Sanders, Orbit Sanders, Polishers,Electric Planers, Electric Sprayers, Electric Nailers, etc. Besides, they are also suitable for power gardening tools, such as Grass Trimmers, Electric Chain Saws, Electric Lawnmowers, Electric Snowthrowers, etc.
產品特征Features
◆可選帶以下鎖定類型 Optional with following lock types:
→無鎖定 No Lock
→閉合鎖定 Lock-on
→斷開鎖定 Lock-off
→斷開鎖定帶閉合鎖定 Lock-off with lock-on
◆可選帶以下附件 Optional with the accessories as follows:
→包軟膠扳機 Trigger covered with rubber (overmolding)
技術數據Technical data
→機械耐久壽命 Mechanical life endurance≥1E5
→電氣耐久壽命 Electrical life endurance≥5E4
→最大沖擊電流 Max.Inrush current at 250V60A
→最大沖擊電流 Max.Inrush currentat 125V96A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥7M Ohm
→基本介電強度 Dielectric strength of function1500V
→加強介電強度 Dielectric strength of reinforced3000V
→環境溫度 Ambient temperature0°C~55°C
→阻燃等級 FlammabilityUL 94V-0
→防護等級 Protection typeIP40
→適用于II類防護器具 Suitable for appliances of protection class II
端子類型Terminals
◆輸入端 Input side:
→2×接線柱端子 Pillar terminals φ=2.6mm or 2.8mm
◆輸出端 Output side:
→2×接線柱端子 Pillar terminals φ=2.6mm or 2.8mm
→4×插入式端子可插入沾錫導線、帶插片端子導線或銅包頭導線
4×Push-in terminals for soldered strands, strands with end sleeves or strands with end claws
★本產品榮獲實用新型專利，專利號：ZL201920465983.4
★Utility Model patented with the no. is ZL201920465983.4
電氣參數和認證 Electric Rating and Certification
